AIR FAN P120

4Pin PWM Design

Durable Low Noise FDB Bearing System

High Cooling Performance Low Noise

High Performance Fan Blades

Proprietary Enhanced Fan Frame

2 in 1 Solution

Premium Cooling Capability
Unmatched Cost Per Performance
The Air Fan P120 is Montech's definitive cooling solution for those not looking for RGB lighting and all focuses on performance, low noise and quality.
Our proprietary Enhance Fan Frame and High Performance Fan Blade's deliver substantial cooling capability but also limits noise emission to reasonable levels. Together with the highly durable low noise FDB bearing system the Air Fan P120 is a perfect match for liquid cooling, air cooling and case cooling systems.
PWM Smart Temp Control
The Air Fan P120 uses smart PWM control, fan speeds will regulate based on system temperature. It Spins faster when heat is higher and lowers RPM under lower loads to effectively and efficiently balance noise and performance only when needed.
High Performance Fan Blades
The Air Fan P120 has taken a large step in fan blade optimization. The outcome is a higher airflow and air pressure blade design.
While at the same time the blades keeps windshear noise controlled and reasonable.

Max RPM — 1,500 RPM
Max Airflow — 73 CFM (ft3 /mm)
Max Noise — 10~27 dBA
Highly Durable FDB Bearing System
With a Fluid Dynamic Bearing (FDB) system, the bearing fluid greatly lowers resistance, vibrations and wear. This greatly increase efficiency, and also makes the fan highly durable to use and wear. Compared to market competitors, the Air Fan P120 can deliver lower noise and cooling performance. Stability at the bearing also means a more durable product without comprise in performance.
Proprietary Enhanced Fan Frame
Montech's Proprietary Enhanced Fan Frame has the benefit of reduced turbulence and lower noise. Effectively improving overall efficiency and performance.


2in1 Solution
The Air Fan P120 comes as a 2in1 solution. Included in each package is a 1to3 PWM
splitter that allows you to plug in to as much as 3 P120's to each 4Pin PWM connector on your mainboard.

SPECIFICATIONS

Model NameAIR FAN P120
Packaging2 in 1 Pack
Dimensions120*120*25mm
Package Dimensions150*123*53mm
Weight360g
Speed600~1500RPM (±10%)
BearingFDB
Voltage Range12V
ConnectorPWM 4Pin
Cable Length500mm
Airflow (Max.)73CFM
Static Pressure (Max.)1.71mmH2O
Noise Level (Max.)27dBA
EAN4710562743333
Warranty1 Year
